Maintenance & Repair 2

company

RevHD

RevHD is a leading manufacturer of premium severe-duty wheel-end components for the commercial trucking industry. Based in Nashville Tennessee the company was founded by industry veterans to simplify maintenance and reduce common causes of wheel-end failure.

REV SEVERE DUTY BEARINGS

PART #	PER CS	EQUIVALENT/DESCRIPTION
RB-427	4	Half Stand Bearing Set-FF Steer-Inner & TN Trailer-Outer (HM212049/HM212011)
RB-428	4	Half Stand Bearing Set-FF Steer-Outer (3782/3720)
RB-429	4	Half Stand Bearing Set-R Drive-Inner (592 A/594 A)
RB-430	4	Half Stand Bearing Set-R Drive-Outer (580/572)
RB-431	4	Half Stand Bearing Set-TN Trailer-Inner (HM218248/HM218210)
RB-432	4	Half Stand Bearing Set-TP Trailer-Inner/Outer (HM518445/HM518410)
RB-445	4	Half Stand Bearing Set-FL Steer-Inner (6461A/6420)
RB-446	4	Half Stand Bearing Set-FL Steer-Outer (555S/552A)

REV SEVERE DUTY SPACERS

PART #	PER CS	DESCRIPTION
RSP-S01	4	Hardened Spacer-FF Steer Preset Hub
RSP-D02	4	Hardened Spacer-Drive Preset Hub
RSP-T03	4	Hardened Spacer-TN Trailer Preset Hub
RSP-T04	4	Hardened Spacer-TP Trailer Preset Hub
RSP-S05	4	Hardened Spacer-FL Steer Preset Hub

REV SEVERE DUTY HUB CAPS AND ACCESSORIES

PART #	PER CS	DESCRIPTION
RHO-S01	8	Oil Hub Cap FF Steer 6 bolt with: Side plug Gasket Bolts & TempBolt (4024)
RHO-T03	8	Oil Hub Cap TN Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4009)
RHO-T04	8	Oil Hub Cap TP Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4195)
RHO-T03PSI	8	Oil PSI Hub Cap TN Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4370)
RHO-T04PSI	8	Oil PSI Hub Cap TP Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4372)

REV DUALLY DRAIN PAN

PART #	PER CS	COST	DESCRIPTION
RD-0001	6		Drain Pan - fits Steers Drives & Trailers (6 Pack)

REV 1 STANDARD WHEEL SEALS (1 YEAR WARRANTY)

PART #	PER CS	EQUIVALENT/DESCRIPTION
R1-S01	12	Standard Steer Seal (383-0136 370001A 35058)
R1-D02	12	Standard Drive Seal (393-0173 370003A 47691)
R1-T03	12	Standard Trailer Seal Tapered Spindle (373-0143 370025A 46300)
R1-T04	12	Standard Trailer Seal Straight Spindle (373-0123 370065A 42627)

REV MAX PREMIUM WHEEL SEALS (3 YEAR WARRANTY)

PART #	PER CS	EQUIVALENT/DESCRIPTION
RM-S01	12	Premium Steer Seal (383-0236 380001A 35058)
RM-D02	12	Premium Drive Seal (393-0273 380003A 47691)
RM-T03	12	Premium Trailer Seal Tapered Spindle (373-0243 380025A 46300)
RM-T04	12	Premium Trailer Seal Straight Spindle (373-0223 380065A 42627)
RM-S05	12	Premium Steer Seal (383-0264 380048A 43761 43763 43764)
RM-D06	12	Premium Drive Seal (393-0204 380031A 42671 42672 42673)
RM-D07	12	Premium Drive Seal (393-0203 380022A 45093 45097 45099)
RM-D08	12	Premium Drive Seal (393-0212 380023A 38780 38776 38779)
RM-T09	12	Premium Trailer Seal (373-0213 380036A 40129 40133 40136)

REV-LOC UNIVERSAL SPINDLE LOCKING NUT AND REUSABLE CLIP

PART #	PER CS	DESCRIPTION
RL-S01	8	FF Steer Universal Spindle Locking Nut (448-4836)
RL-S02	8	FE Steer Universal Spindle Locking Nut (448-4837)
RL-D02	8	Drive Universal Spindle Locking Nut (449-4973)
RL-T03	8	TN Trailer Universal Spindle Locking Nut (447-4743)
RL-T04	8	TP Trailer Universal Spindle Locking Nut (447-4723)

REV SEVERE DUTY HUB CAPS AND ACCESSORIES

PART #	PER CS	DESCRIPTION
RHG-T03	12	Grease Hub Cap TN Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4009)
RHG-T04	12	Grease Hub Cap TP Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4195)
RHG-T03PSI	12	Grease PSI Hub Cap TN Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4370)
RHG-T04PSI	12	Grease PSI Hub Cap TP Trailer 6 bolt with: Side plug Gasket Bolts & TempBolt (4372)
RG-S01	12	Gaskets for all RevHD Steer Hub Caps 4024 (12-pack)
RG-T03	12	Gaskets for all RevHD TN Trailer Hub Caps 4009 (12-pack)
RG-T04	12	Gaskets for all RevHD TP Trailer Hub Caps 4195 (12-pack)
RP-0002	12	Replacement Rubber Plugs 1 1/8" (12-pack)
RT-0003	12	Replacement Heat-Check Bolts (12-pack)
RT-0004	12	Replacement Hub Cap Bolts Grade 5 Zinc Plated (12-pack)

company

S.U.R.&R.

S.U.R.&R. (Service Utility Repair & Replacement) is an American manufacturer specialized in innovative fluid line repair solutions for the automotive industry. Now a division of Husky Corporation they are the go-to brand for technicians who want to repair lines rather than replace expensive hard-to-find factory assemblies.

HOSE SPRING

PART #	DESCRIPTION	COST
SP34	3/4" Heater Hose Spring (3")

TOOLS

PART #	DESCRIPTION	COST
CP90	Heavy Duty Ratcheting Seal Clamp Pliers (1)
CP360	360° Seal Clamp Pliers (1)

HOSE SPLICERS

PART #	DESCRIPTION	COST
CLC212	1/2" Hose Splicer (2)
CLC258	5/8" Hose Splicer (2)
CLC234	3/4" Hose Splicer (2)
CLC25834	3/4" x 5/8" Hose Splicer Reducer (2)
CLC13490	3/4" 90° Elbow (2)

SAE CONNECTORS

PART #	DESCRIPTION	COST
CLC95858	5/8"-5/8" Straight Quick Connect (2)
CLC93434	3/4"-3/4" Straight Quick Connect (2)
CLC93458	3/4"-5/8" Straight Quick Connect (2)
CLC85858	5/8"-5/8" 90° Quick Connect (2)
CLC83434	3/4"-3/4" 90° Quick Connect (2)
CLC83458	3/4"-5/8" 90° Quick Connect (2)

VDA CONNECTORS

PART #	DESCRIPTION	COST
CLC61258	12mm VDA-5/8" Straight Quick Connect (2)
CLC70812	8mm VDA-1/2" 90° Quick Connect
CLC71258	12mm VDA-5/8" 90° Quick Connect (2)

COOLANT KIT

PART #	DESCRIPTION	COST
CLC50	Coolant Line Connector Repair Kit (1)
HL427	Heater Line Repair Kit (1)

COMPRESSION UNIONS

PART #	DESCRIPTION	COST
HL12	1/2" Heater Compression Union (1)
HL58	5/8" Heater Compression Union (1)
HL34	3/4" Heater Compression Union (1)

HOSE TO COMPRESSION UNION ADAPTERS

PART #	DESCRIPTION	COST
HL11212	1/2" Hose to 1/2" Compression Union (1)
HL11258	1/2" Hose to 5/8" Compression Union (1)
HL11234	1/2" Hose to 3/4" Compression Union (1)

HOSE (UNIVERSAL HOSE USE WITH ALL S.U.R.&R. HEATER ADAPTERS)

PART #	DESCRIPTION	COST
HL12H	1/2" Heater Hose (10')
HL12H25	1/2" Heater Hose (25')

CLAMPS & CLIPS

PART #	DESCRIPTION	COST
HL34C	3/4" Heater Hose Dual Clamp (5)
CLC358	5/8" Retaining Clip (4)
CLC334	3/4" Retaining Clip (4)
K6811	7/8" Seal Clamp (10)
K6812	15/16" Seal Clamp (10)
K6814	1-1/8" Seal Clamp (10)

CLAMPS SETS

PART #	DESCRIPTION	COST
AC6806	#6 Clamps Set (5)
AC6808	#8 Clamps Set (5)
AC6810	#10 Clamps Set (5)
AC6812	#12 Clamps Set (5)

HOSE SPLICERS

PART #	DESCRIPTION	COST
AC370606	#6 Hose to #6 Hose In Line Splicer (1)
AC370808	#8 Hose to #8 Hose In Line Splicer (1)
AC371010	#10 Hose to #10 Hose In Line Splicer (1)
AC371212	#12 Hose to #12 Hose In Line Splicer (1)

TOOLS

PART #	DESCRIPTION	COST
CP90	Heavy Duty Ratcheting Seal Clamp Pliers (1)
CP360	360° Seal Clamp Pliers (1)
TC35	Tube & Hose Cutter (1)

LINE REDUCERS

PART #	DESCRIPTION	COST
AC1612	#6 Hose to 1/2" Compression Union (1)
AC1858	#8 Hose to 5/8" Compression Union (1)
AC11034	#10 Hose to 3/4" Compression Union (1)

INLINE SERVICE PORTS

PART #	DESCRIPTION	COST
AC412L	1/2" Service Port Valve - Low Side (1)
AC458L	5/8" Service Port Valve - Low Side (1)
AC438H	3/8" Service Port Valve - High Side (1)
AC412H	1/2" Service Port Valve - High Side (1)

HOSE TO TUBE ADAPTERS

PART #	DESCRIPTION	COST
AC43806	#6 Hose to 3/8" Tube Adapter (1)
AC41208	#8 Hose to 1/2" Tube Adapter (1)
AC45810	#10 Hose to 5/8" Tube Adapter (1)

HOSE

PART #	DESCRIPTION	COST
AC6H	#6 A/C Hose (10')
AC6H25	#6 A/C Hose (25')
AC8H	#8 A/C Hose (10')
AC8H25	#8 A/C Hose (25')
AC10H	#10 A/C Hose (10')
AC10H25	#10 A/C Hose (25')
AC12H	#12 A/C Hose (10')
AC12H25	#12 A/C Hose (25')

AC LINE REPAIR & IN-LINE FILTER KIT

PART #	DESCRIPTION	COST
AC128	A/C Line Repair/In Line Filter Kit (1)

HOSE TO COMPRESSION UNION ADAPTERS - SAE

PART #	DESCRIPTION	COST
AC16516	#6 Hose to 5/16" Compression Union (1)
AC1638	#6 Hose to 3/8" Compression Union (1)
AC1812	#8 Hose to 1/2" Compression Union (1)
AC11058	#10 Hose to 5/8" Compression Union (1)
AC11234	#12 Hose to 3/4" Compression Union (1)

HOSE TO COMPRESSION UNION ADAPTERS - METRIC

PART #	DESCRIPTION	COST
AC168M	#6 Hose to 8mm Compression Union (1)
AC1610M	#6 Hose to 10mm Compression Union (1)
AC1812M	#8 Hose to 12mm Compression Union (1)
AC110145M	#10 Hose to 14.5mm Compression Union (1)
AC11015M	#10 Hose to 15mm Compression Union (1)
AC11016M	#10 Hose to 16mm Compression Union (1)
AC11219M	#12 Hose to 19mm Compression Union (1)
AC26516	#6 Hose to 90° 5/16" Compression Union (1)
AC2638	#6 Hose to 90° 3/8" Compression Union (1)
AC2812	#8 Hose to 90° 1/2" Compression Union (1)
AC21058	#10 Hose to 90° 5/8" Compression Union (1)
AC21234	#12 Hose to 90° 3/4" Compression Union (1)

AC KITS

PART #	DESCRIPTION	COST
AC1387	Deluxe A/C Line Repair Kit (1)
AC40	A/C Compression Union Kit (1)
AC50M	Metric A/C Compression Union Kit (1)
AC80	A/C Compression Block Off Kit (1)
AC90M	Metric A/C Compression Block Off Kit (1)

COMPRESSION BLOCK OFFS - SAE

PART #	DESCRIPTION	COST
AC516C	5/16" A/C Compression Block Off (1)
AC38CB	3/8" A/C Compression Block Off (1)
AC12CB	1/2" A/C Compression Block Off (1)
AC58CB	5/8" A/C Compression Block Off (1)
AC34CB	3/4" A/C Compression Block Off (1)
AC8MCB	8mm A/C Compression Union (1)
AC10MCB	10mm A/C Compression Union (1)
AC12MCB	12mm A/C Compression Union (1)
AC145MCB	14.5mm A/C Compression Block Off (1)
AC15MCB	15mm A/C Compression Union (1)
AC16MCB	16mm A/C Compression Union (1)
AC19MCB	19mm A/C Compression Union (1)

COMPRESSION UNIONS - SAE

PART #	DESCRIPTION	COST
AC516	5/16" A/C Compression Union (1)
AC38	3/8" A/C Compression Union (1)
AC12	1/2" A/C Compression Union (1)
AC58	5/8" A/C Compression Union (1)
AC34	3/4" A/C Compression Union (1)
AC8M	8mm A/C Compression Union (1)
AC10M	10mm A/C Compression Union (1)
AC12M	12mm A/C Compression Union (1)
AC145M	14.5mm A/C Compression Union (1)
AC15M	15mm A/C Compression Union (1)
AC16M	16mm A/C Compression Union (1)
AC19M	19mm A/C Compression Union (1)

CHECK VALVES AND INLINE SERVICE PORTS

PART #	DESCRIPTION	COST
CKV5	5/16" Check Valve (1)
CKV7	3/8" Check Valve (1)
SV38	3/8" In-Line Schrader Valve (1)
SV516	5/16" In-Line Schrader Valve (1)

CLAMPS & TUBING HOLDERS

PART #	DESCRIPTION	COST
K2978	1/4" Seal Clamp (10)
K2980	5/16" Seal Clamp (10)
K2982	3/8" Seal Clamp (10)
K2984	1/2" Seal Clamp (10)
TH38	3/8" Nylon Tube Holder (20)
TH516	5/16" Nylon Tube Holder (20)

PROTECTIVE SLEEVES

PART #	DESCRIPTION	COST
14005	Heat Shield Sleeve (5')
K710	3/8" Expandable Braided Sleeving (25')

TOOLS

PART #	DESCRIPTION	COST
CP01	Clamp Pliers (1)
CP90	Heavy Duty Ratcheting Seal Clamp Pliers (1)
CP360	360° Seal Clamp Pliers (1)
TC-1	Tube Cutter (1)

PUSH-TO-CONNECT NYLON UNIONS

PART #	DESCRIPTION	COST
K510	1/4" Nylon To Nylon Straight Union (2)
K520	5/16" & 8mm Nylon To Nylon Straight Union (2)
K530	3/8" & 10mm Nylon To Nylon Straight Union (2)
K540	1/2" Nylon To Nylon Straight Union (2)
K560	1/4" Nylon To Nylon 90° Union (2)
K570	5/16" & 8mm Nylon To Nylon 90° Union (2)
K580	3/8" & 10mm Nylon To Nylon 90° Union (2)
K590	1/2" Nylon To Nylon 90° Union (2)

QUICK FIT FLEXIBLE FUEL LINE SET

PART #	DESCRIPTION	COST
FL205	Quick-Fit Flexible Fuel Line Set (1)
FL210	Quick-Fit Flexible Fuel Line Set (1)
FL215	Quick-Fit Flexible Fuel Line Set (1)

NYLON TUBING

PART #	DESCRIPTION	COST
K003	1/4" Nylon Tubing (25')
K00350	1/4" Nylon Tubing (50')
K003100	1/4" Nylon Tubing (100')
K005	5/16" Nylon Tubing (25')
K00550	5/16" Nylon Tubing (50')
K005100	5/16" Nylon Tubing (100')
K010	3/8" Nylon Tubing (25')
K01050	3/8" Nylon Tubing (50')
K010100	3/8" Nylon Tubing (100')
K405	1/2" Nylon Tubing (25')

UNIONS

PART #	DESCRIPTION	COST
K050	5/16" Nylon To Steel Compression Fitting (2)
K055	5/16" Nylon To Nylon Compression Fitting (2)
K060	3/8" Nylon To Steel Compression Fitting (2)
K065	3/8" Nylon to Nylon Compression Fitting (2)
K250	1/4" Nylon To Steel Compression Fitting (2)
K255	1/4" Nylon To Nylon Compression Fitting (2)
K430	1/2" Nylon To Steel Compression Fitting (2)
K057	5/16" Nylon To Nylon Push-On Union (2)
K067	3/8" Nylon To Nylon Push-On Union (2)
K425	1/2" Nylon To Nylon Push-On Union (2)

LINE ADAPTERS

PART #	DESCRIPTION	COST
K150	5/16" Quick Connect To Nylon Connector (2)
K155	3/8" Quick Connect To Nylon Connector (2)
K420	1/2" Quick Connect To Nylon Connector (2)
K445	12mm Quick Connect to 1/2" Nylon Connector (2)
K153	3/8" Quick Connect to Quick Connect (2)
K160	1/4" Quick Disconnect To 5/16" Nylon Connector (2)
K165	3/8"-5/16" Nylon To Nylon Reducer (2)
K167	5/16"-1/4" Nylon to Nylon Reducer (2)
K170	5/16" GM Male To Rubber Hose Connector (2)
K175	3/8" GM Male To Rubber Hose Connector (2)
K270	5/16" GM Short Line Adapter (2)
K275	3/8" GM Short Line Adapter (2)
K305	9/16"-5/16" Male Spring Lock To Nylon (1)
K315	7/16"-5/16" Male Spring Lock To Nylon (1)
K310	9/16"-5/16" Female Spring Lock To Nylon (1)
K320	7/16"-5/16" Female Spring Lock To Nylon (1)
K325	12mm-5/16" Banjo To Nylon (1)
K335	14mm-5/16" Banjo To Nylon (1)
K330	12mm-5/16" Banjo Bolt To Nylon (1)
38180	180 Degree GM Fuel Filter Line Adapter (1)
3890	3/8" 90 Degree Elbow (2)
51690	5/16" 90 Degree Elbow (2)

UNIVERSAL QUICK CONNECTS

PART #	DESCRIPTION	COST
KP130	3/8"-5/16" 90 Degree Push Quick Connect (2)
KP135	5/16"-5/16" 90 Degree Push Quick Connect (2)
K415	1/2"-1/2" 90 Degree Push Quick Connect (2)
K440	12mm-1/2" 90 Degree Push Quick Connect (2)

LINE ADAPTERS

PART #	DESCRIPTION	COST
K070	5/16" GM Line Adapter (2)
K075	3/8" GM Line Adapter (2)
K095	5/16" GM Female To Nylon Adapter (1)
K100	3/8" GM Female To Nylon Adapter (1)
K107	14mm Foreign To Nylon Line Adapter (1)
K127	14mm Foreign Angle Line Adapter (2)
K137	14mm Foreign Line Adapter (2)
K140	5/16" Nylon To Hose Connector (2)
K145	3/8" Nylon To Hose Connector (2)

FUEL KITS

PART #	DESCRIPTION	COST
KP1500	Deluxe Fuel Line Replacement Kit (1)
KP1200	Fuel Line Replacement Kit (1)
KP1212	1/2" & 12mm Fuel Line Replacement Kit (1)
K555	Nylon Fuel Line Union Assortment (1)

UNIVERSAL QUICK CONNECTS

PART #	DESCRIPTION	COST
KP020	3/8"-3/8" Straight Push Quick Connect (2)
KP030	3/8"-5/16" Straight Push Quick Connect (2)
KP035	5/16"-3/8" Straight Push Quick Connect (2)
KP040	5/16"-5/16" Straight Push Quick Connect (2)
K410	1/2"-1/2" Straight Push Quick Connect (2)
K435	12mm-1/2" Straight Push Quick Connect (2)
KP045	1/4"-5/16" Straight Push Quick Connect (2)
KP120	5/16"-3/8" 90 Degree Push Quick Connect (2)
KP125	3/8"-3/8" 90 Degree Push Quick Connect (2)

AIR BRAKE FITTINGS

PART #	DESCRIPTION	COST
ABM220	Straight Male Connector 1/4" Tube X 1/8" NPT (2)
ABM230	Straight Male Connector 1/4" Tube X 1/4" NPT (2)
ABM240	Straight Male Connector 1/4" Tube X 3/8" NPT (2)
ABM320	Straight Male Connector 3/8" Tube X 1/8" NPT (2)
ABM330	Straight Male Connector 3/8" Tube X 1/4" NPT (2)
ABM340	Straight Male Connector 3/8" Tube X 3/8" NPT (2)
ABM550	Straight Male Connector 5/8" Tube X 1/2" NPT (2)
ABP300	3/8" Tube Plug (2)
ABT200	Union Tee 1/4" Tube (2)
ABT300	Union Tee 3/8" Tube (2)
ABT330	Male Run Tee 3/8" Tube X 1/4" NPT (2)
ABU200	Straight Union 1/4" Tube (2)
ABU300	Straight Union 3/8" Tube (2)
ABU400	Straight Union 1/2" Tube (2)

AIR BRAKE REPAIR KIT

PART #	DESCRIPTION	COST
AB25	Air Brake Repair Kits (1)

AIR BRAKE FITTINGS

PART #	DESCRIPTION	COST
AB4230	45° Swivel Male Elbow 1/4" Tube X 1/4" NPT (2)
AB4340	45° Swivel Male Elbow 3/8" Tube X 3/8" NPT (2)
ABE200	Union Elbow 1/4" Tube (2)
ABE220	Male Elbow 1/4" Tube X 1/8" NPT (2)
ABE230	Male Elbow 1/4" Tube X 1/4" NPT (2)
ABE240	Male Elbow 1/4" Tube X 3/8" NPT (2)
ABE320	Male Elbow 3/8" Tube X 1/8" NPT (2)
ABE330	Male Elbow 3/8" Tube X 1/4" NPT (2)
ABE340	Male Elbow 3/8" Tube X 3/8" NPT (2)
ABE550	Male Elbow 5/8" Tube X 1/2" NPT (2)
ABF220	Female 1/4" Tube X 1/8" NPT (2)

COPPER WASHER ASSORTMENT

PART #	DESCRIPTION	COST
BRC7	Copper Washer Assortment (1)

COPPER WASHERS

PART #	DESCRIPTION	COST
BRC127	3/8" Copper Washer (10)
BRC137	7/16" Copper Washer (10)
BRC147	1/2" Copper Washer (10)
BRC157	9/16" Copper Washer (10)
BRC227	10mm Copper Washer (10)
BRC247	12mm Copper Washer (10)
BRC277	15mm Copper Washer (10)
BRC287	16mm Copper Washer (10)

BRAKE BLEEDER KIT

PART #	DESCRIPTION	COST
BB007	Brake Bleeder Removal Tool (1)

BLEEDER SCREWS, CAPS & PINS

PART #	DESCRIPTION	COST
BB01	M10 x 1.0S Bleeder Screw (5)
BB02	3/8" - 24 Bleeder Screw (5)
BB03	5/16" - 24 Bleeder Screw (5)
BB04	1/4" - 28 Bleeder Screw (5)
BB05	M10 x 1.25 Bleeder Screw (5)
BB06	M10 x 1.5 Bleeder Screw (5)
BB07	M7 x 1.0 Bleeder Screw (5)
BB08	7/16" - 24NS Bleeder Screw (5)
BB09	M8 x 1.25 Bleeder Screw (5)
BB10	M8 x 1.0 Bleeder Screw (5)
BB11	7/16" - 20NF Bleeder Screw (5)
BB12	M10 x 1.0L Bleeder Screw (5)
BB20	Small Dust Cap (5)
BB21	Large Dust Cap (5)
BBPIN	Brake Bleeder Screw Pins
BBTOOL	BB007 Tool (1)

MAX FLEX TUBING

PART #	DESCRIPTION	COST
BCC325	3/16" Max Flex Brake Line (25')
BCC350	3/16" Max Flex Brake Line (50')
BCC3100	3/16" Max Flex Brake Line (100')
BCC425	1/4" Max Flex Brake Line (25')
BCC450	1/4" Max Flex Brake Line (50')
BCC4100	1/4" Max Flex Brake Line (100')
BCC525	5/16" Max Flex Tubing (25')
BCC625	3/8" Max Flex Tubing (25')

MAX FLEX BUNDLES

PART #	DESCRIPTION	COST
BCC325B	3/16" Max Flex Quick-Fix Brake Line Bundle (1)
BCC425B	1/4" Max Flex Quick-Fix Brake Line Bundle (1)

UNIONS

PART #	DESCRIPTION	COST
BR405	3/8"-24 Inverted Flare Union (4)
BR435	M10 x 1.0 Inverted Flare Union (4)
BR450	M10 x 1.0 Bubble Flare Union (4)
BR4100	7/16" - 24 Inverted Flare Union (1)

INVERTED FLARE NUTS

PART #	DESCRIPTION	COST
BR1150	7/16"-24 Inverted Flare Nut (4)
BR1200	7/16"-24 Inverted Flare Nut [9/16" Wrench] (4)
BR1400	7/16"-24L Inverted Flare Nut (4)
BR1600	9/16"-18 Inverted Flare Nut (4)
BR1650	1/2"-20 Inverted Flare Nut (4)

BUBBLE FLARE NUTS

PART #	DESCRIPTION	COST
BR170	3/8"-24 Bubble Flare Nut (4)
BR230	M10 x 1.0 Bubble Flare Nut [Euro Domestic] (4)
BR235	M11 x 1.5 Bubble Flare Nut (4)
BR240	M12 x 1.0 Bubble Flare Nut (4)
BR245	M13 x 1.5 Bubble Flare Nut (4)
BR250	M10 x 1.0 Bubble Flare Nut [VW Audi] (4)
BR255	M10 x 1.0 Bubble Flare Nut [Ford] (4)
BR2200	M12 x 1.0 Bubble Flare Nut (4)
BR2300	M13 x 1.5 Bubble Flare Nut (4)
BR2500	M14 x 1.5 Bubble Flar Nut [GM] (4)

ADAPTERS

PART #	DESCRIPTION	COST
BR500	3/8"-24 Inverted Female to M10 x 1.0 Inverted Male (4)
BR505	3/8"-24 Inverted Female to M10 x 1.0 Bubble Male (4)
BR550	3/8"-24 Inverted Female to 7/16"-24 Inverted Male (4)
BR555	3/8"-24 Inverted Female to 1/2"-20 Inverted Male (4)
BR560	3/8"-24 Inverted Female to 9/16"-18 Inverted Male (4)
BR510	M10 x 1.0 Bubble Female to M11 x 1.5 Bubble Male (4)

BRAKE KITS

PART #	DESCRIPTION	COST
BR-EZ316	3/16" Brake Line Kit (1)
BR-EZ14	1/4" Brake Line Kit (1)
BR316	3/16" Brake Line Fitting Assortment (1)
BR14	1/4" Brake Line Fitting Assortment (1)

ULTRABEND TUBING

PART #	DESCRIPTION	COST
BR-EZ100	3/16" UltraBEND Brake Line (25')
BR-EZ100-50	3/16" UltraBEND Brake Line (50')
BR-EZ100-100	3/16" UltraBEND Brake Line (100')
BR-EZ200	1/4" UltraBEND Brake Line (25')
BR-EZ200-50	1/4" UltraBEND Brake Line (50')
BR-EZ200-100	1/4" UltraBEND Brake Line (100')
BR-EZ300	5/16" UltraBEND Tubing (25')
BR-EZ400	3/8" UltraBEND Tubing (25')

INVERTED FLARE NUTS

PART #	DESCRIPTION	COST
BR105	3/8"-24 Inverted Flare Nut (4)
BR135	3/8"-24L Inverted Flare Nut (4)
BR145	7/16"-24 Inverted Flare Nut (4)
BR150	1/2"-20 Inverted Flare Nut (4)
BR155	9/16"-18 Inverted Flare Nut (4)
BR157	3/8"-24 Inverted Flare Nut [7/16" Wrench] (4)
BR205	M10 x 1.0 Gold Inverted Flare Nut (4)
BR210	M10 x 1.0 Blue Inverted Flare Nut (4)
BR270	M10 x 1.0L Inverted Flare Nut (4)

SPECIALTY TOOLS

PART #	DESCRIPTION	COST
BTB5K	Brake Tool Assortment
BTB6P	Brake Pro Bundle (1)
CP720	Dual Jaw 360° Seal Clamp Pliers (1)
CT500	Universal Clamp Making Tool Kit (1)
DPR350	Drain Plug Removal Kit
DT440	4 Pc. Air Line Disconnect Tool Set (1)
EGR21	3/16" Flexible EGR Drill Bit - 21" (1)
EGR312	EGR Port Cleaning Kit (1)
FA100	Flex Air Blow Gun (1)
FC25	Filter Removal Cup
FC5	Filter Removal Cup
FIC203	Fuel Injection Cleaner Kit
FIC903	Intake System Cleaner Canister (1)
FLS330	3/8" Expandable Braided Sleeving (25')
FPT22	Deluxe Fuel Injection Pressure Tester Kit (1)
FPT290	Deluxe Fuel Pressure Tester Adapter Kit (1)
FT351	Deluxe Flaring Tool (1)
FT351M	Multi-Size Tubing Bender (1)
GM64	Fuel Level Sensor Contacts (1)
HFT50	HYDRA-Assist Flaring Tool (1)
NR3	3 pc. 2.5° Nano-Ratchet Set (1)
PFT409	Pistol Grip Flaring Tool
RLW400	Ratcheting Line Wrench Set (1)
RLW450	Ratcheting Line Wrench Set (1)
RM21	Inside/Outside Tube Deburring Tool
RM69	Brake Tubing Reamer (1)
SRUJ3	3 pc. Spring-Return U-Joint Adapter Set (1)
S-TOOL	S-Hook Sprayer (1)
TAS3	Temporary Air Supply (1)
TC35B	TC35 Replacement Blade
TC40	Ratchet-Action Tubing Cutter
TC40B	TC40 Replacement Cutting Blade
TC60	Automatic/Ratcheting Tubing Cutter (1)
TC60B	TC60 Replacement Cutting Blade (1)
TFS203	Temporary Fuel Supply (1)
TP14316	2 in 1 Tubing Benders (1)
TP3153	Multi Size Tubing Bender
TS14316	Tubing Straightener and Bending Pliers (1)
TS224	Tubing Straightener
UT10	Black ULTRA Tough Tape (10')
UT15	ULTRA Tough Tape (10')

HIGH PRESSURE COMPRESSION UNION ASSORTMENT

PART #	DESCRIPTION	COST
HP200	HNBR O-Ring Assortment (1)

HIGH PRESSURE COMPRESSION UNIONS

PART #	DESCRIPTION	COST
HP14	1/4" High Pressure Compression Union (1)
HP316	3/16" High Pressure Compression Union (1)

HNBR O-RING ASSORTMENT

PART #	DESCRIPTION	COST
HOR350	HNBR O-Ring Assortment (1)

HNBR O-RINGS

PART #	DESCRIPTION	COST
HOR110	4.5 x 1.5 HNBR O-Ring (50)
HOR120	4.48 x 1.78 HNBR O-Ring (50)
HOR140	6.07 x 1.78 HNBR O-Ring (50)
HOR150	7 x 1.5 HNBR O-Ring (50)
HOR160	6.5 x 2 HNBR O-Ring (50)
HOR170	7.2 x 1.78 HNBR O-Ring (50)
HOR220	7.66 x 1.78 HNBR O-Ring (50)
HOR230	6 x 2.5 HNBR O-Ring (50)
HOR240	8 x 2 HNBR O-Ring (50)
HOR260	9.25 x 1.78 HNBR O-Ring (50)
HOR270	10 x 1.9 HNBR O-Ring (50)
HOR280	9 x 2.62 HNBR O-Ring (50)
HOR410	9.8 x 1.9 HNBR O-Ring (50)
HOR430	10.82 x 1.78 HNBR O-Ring (50)
HOR440	9.19 x 2.62 HNBR O-Ring (50)
HOR460	10 x 2.5 HNBR O-Ring (50)
HOR470	11.11 x 2.38 HNBR O-Ring (50)
HOR480	12 x 2 HNBR O-Ring (50)
HOR510	12.42 x 1.78 HNBR O-Ring (50)
HOR520	10.77 x 2.62 HNBR O-Ring (50)
HOR540	12.7 x 1.58 HNBR O-Ring (50)
HOR550	13 x 2 HNBR O-Ring (50)
HOR570	12 x 2.5 HNBR O-Ring (50)
HOR580	13.9 x 1.8 HNBR O-Ring (50)
HOR620	12.37 x 2.62 HNBR O-Ring (50)
HOR640	14.8 x 2.4 HNBR O-Ring (50)
HOR660	14.28 x 2.38 HNBR O-Ring (50)
HOR680	15.6 x 1.78 HNBR O-Ring (50)
HOR720	13.95 x 2.62 HNBR O-Ring (50)
HOR740	14.2 x 2.62 HNBR O-Ring (50)
HOR760	17.17 x 1.78 HNBR O-Ring (50)
HOR780	15.8 x 2.62 HNBR O-Ring (50)
HOR830	19 x 2.5 HNBR O-Ring (50)
HOR870	20 x 3.5 HNBR O-Ring (50)

HOSE CLAMP ASSORTMENT

PART #	DESCRIPTION	COST
HC102	Hose Clamp Assortment (1)

HOSE CLAMPS

PART #	DESCRIPTION	COST
K2978	1/4" Seal Clamp (10)
K2980	5/16" Seal Clamp (10)
K2982	3/8" Seal Clamp (10)
K2984	1/2" Seal Clamp (10)
K6806	9/16" Seal Clamp (10)
K6807	11/16" Seal Clamp (10)
K6808	23/32" Seal Clamp (10)
K6810	3/4" Seal Clamp (10)
K6811	7/8" Seal Clamp (10)
K6812	15/16" Seal Clamp (10)

TOOL

PART #	DESCRIPTION	COST
CP90	Heavy Duty Ratcheting Seal Clamp Pliers (1)
CP360	360° Seal Clamp Pliers (1)

OIL DRAIN PLUG GASKET ASSORTMENT

PART #	DESCRIPTION	COST
DPG120	Oil Drain Plug Assortment (1)

OIL DRAIN PLUG GASKETS

PART #	DESCRIPTION	COST
DPG205	M12 Nylon Oil Drain Plug Gasket (10)
DPG220	1/2"(M12) Nylon Oil Drain Plug Gasket (10)
DPG225	1/2"(M12) Large Nylon Oil Drain Plug Gasket (10)
DPG235	M14 Nylon Oil Drain Plug Gasket (10)
DPG240	9/16" Nylon Oil Drain Plug Gasket (10)
DPG260	5/8" Nylon Oil Drain Plug Gasket (10)
DPG270	11/16" Nylon Oil Drain Plug Gasket (10)
DPG280	3/4" Nylon Oil Drain Plug Gasket (10)
DPG290	7/8" Nylon Oil Drain Plug Gasket (10)
DPG305	M12 Fiber Oil Drain Plug Gasket (10)
DPG330	1/2" Fiber Oil Drain Plug Gasket (10)
DPG340	9/16" Fiber Oil Drain Plug Gasket (10)
DPG375	M18 Fiber Oil Drain Plug Gasket (10)
DPG385	M20 Fiber Oil Drain Plug Gasket (10)
DPG420	1/2"(M12) Copper Oil Drain Plug Gasket (10)
DPG440	9/16" Copper Oil Drain Plug Gasket (10)
DPG460	5/8"(M16) Copper Oil Drain Plug Gasket (10)
DPG480	3/4" Copper Oil Drain Plug Gasket (10)
DPG530	14.5mm Aluminum Oil Drain Plug Gasket (10)
DPG605	1/2" Copper Crush Oil Drain Plug Gasket (10)
DPG705	M12 Rubber Oil Drain Plug Gasket (10)
DPG730	M14 Rubber Oil Drain Plug Gasket (10)
DPG810	1/2" Rubber/Metal Oil Drain Plug Gasket (10)
DPG830	9/16" Rubber/Metal Oil Drain Plug Gasket (10)

OIL DRAIN PLUG ASSORTMENT

PART #	DESCRIPTION	COST
DP454	Oil Drain Plug Assortment (1)

OIL DRAIN PLUGS

PART #	DESCRIPTION	COST
DP105	1/2"-20 Single Oversized Oil Drain Plug (5)
DP110	1/2"-20 Double Oversized Oil Drain Plug (5)
DP115	1/2"-20 Triple Oversized Oil Drain Plug (5)
DP150	1/2"-20 Single Oversized Piggyback Oil Drain Plug (5)
DP155	1/2"-20 Double Oversized Piggyback Oil Drain Plug (5)
DP205	1/2"-20 Standard Oil Drain Plug (5)
DP210	1/2"-20 Pilot Point Oil Drain Plug (5)
DP305	M12-1.25 Standard Oil Drain Plug (5)
DP310	M12-1.75 Pilot Point Oil Drain Plug (5)
DP315	M14-1.5 Standard Oil Drain Plug (5)
DP320	M18-1.5 Standard Oil Drain Plug (5)
DP325	M20-1.5 Standard Oil Drain Plug (5)
DP330	M12-1.75 Pilot Point w/ Inset Gasket Oil Drain Plug (5)
DP335	M14-1.5 Standard Oil Drain Plug (5)
DP340	M14-1.5 Pilot Point Oil Drain Plug (5)
DP345	M14-1.25 Pilot Point Oil Drain Plug (5)
DP350	M12-1.75 Pilot Point w/ Inset Gasket Oil Drain Plug (5)

HANGER CLAMP ASSORTMENT

PART #	DESCRIPTION	COST
CL484	Hanger Clamp Assortment

HANGER CLAMPS

PART #	DESCRIPTION	COST
CL14	1/4" Hanger Clamps (10)
CL516	5/16" Hanger Clamps (10)
CL38	3/8" Hanger Clamps (10)
CL12	1/2" Hanger Clamps (10)
CL58	5/8" Hanger Clamps (10)
CL34	3/4" Hanger Clamps (10)

TUBE NUTS AND ADAPTERS

PART #	DESCRIPTION	COST
PS2105	5/16" Male Tube Nut M14 x 1.5 (2)
PS2120	5/16" Male Tube Nut 1/2" x 20 (2)
PS2125	3/8" Male Tube Nut 5/8" x 18 (2)
PS2110	3/8" Male Tube Nut M16 x 1.5 (2)
PS2115	3/8" Male Tube Nut M18 x 1.5 (2)
PS2205	5/16" Female Tube Nut 1/2" x 20 (2)
PS2210	3/8" Female Tube Nut 9/16" x 18 (2)
PS2215	3/8" Female Tube Nut 5/8" x 18 (2)
PS2220	3/8" Female Tube Nut M16 x 1.5 (2)
PS2305	M14 Banjo 1/2" x 20 Thread (1)
PS2310	M14 Banjo 1/2" x 20L Thread (1)
PS2315	M16 Banjo 9/16" x 18L Thread (1)
PS2405	1/2" x 20 - 1/2" x 20 Bump Tube Adapter (1)
PS2410	M16 x 1.5 - 9/16" x 18 Bump Tube Adapter (1)
PS2415	M18 x 1.5 - 9/16" x 18 Bump Tube Adapter (1)

ULTRABEND TUBING

PART #	DESCRIPTION	COST
BR-EZ300	5/16" UltraBEND Tubing (25')
BR-EZ400	3/8" UltraBEND Tubing (25')

POWER STEERING KITS

PART #	DESCRIPTION	COST
PS1000	3/8" Power Steering Hose Repair Kit (1)
PS1000M	10mm Power Steering Hose Repair Kit (1)
PS2000	Power Steering Hose Replacement Kit (1)

HOSES

PART #	DESCRIPTION	COST
PS16	3/8" x 6" Power Steering Hose (1)
PS112	3/8" x 12" Power Steering Hose (1)
PS118	3/8" x 18" Power Steering Hose (1)
PS124	3/8" x 24" Power Steering Hose (1)
PS130	3/8" x 30" Power Steering Hose (1)
PS16M	10mm x 6" Power Steering Hose (1)
PS112M	10mm x 12" Power Steering Hose (1)
PS118M	10mm x 18" Power Steering Hose (1)
PS124M	10mm x 24" Power Steering Hose (1)
PS130M	10mm x 30" Power Steering Hose (1)

COMPRESSION UNION FERRULES

PART #	DESCRIPTION	COST
PS810	5/16" Compression Union Ferrule (2)
PS810M	8mm Compression Union Ferrule (2)
PS820	3/8" Compression Union Ferrule (2)
PS820M	10mm Compression Union Ferrule (2)

TRANSMISSION KITS

PART #	DESCRIPTION	COST
TR555	Deluxe Transmission Oil Cooler Line Repair Kit (1)

RUBBER HOSE

PART #	DESCRIPTION	COST
TR516H	5/16" Transmission Rubber Hose - Universal (use for both 5/16" & 3/8" repairs)

LINE CONNECTORS

PART #	DESCRIPTION	COST
TR750	Dodge/Jeep Trany Line Connector (1)
TR755	Ford Trany Line Connector (1)
TR760	GM Trany Line Connector (1)
TR765	GM Trany Line Connector (1)
TR770	GM Trany Line Connector (1)

LINE NUTS

PART #	DESCRIPTION	COST
TR605	3/8" Inverted Flare Nut 5/8"-18 (4)
TR610	3/8" Bubble Flare Nut M16 x 1.5 (4)
TR615	3/8" Bubble Flare Nut M18 x 1.5 (4)
TR620	3/8" Inverted Flare Nut [5/8"-18 w/Dog Ear] (2)

UNIVERSAL QUICK CONNECTS

PART #	DESCRIPTION	COST
TR720	3/8" Straight Push Quick Connect to Rubber (2)

LINE ADAPTERS

PART #	DESCRIPTION	COST
TR405	5/16" Steel Compression to 5/16" Rubber (2)
TR410	3/8" Steel Compression to 5/16" Rubber (2)
TR935	5/16" Inverted Flare w/ 5/8"-18 Nut to Rubber (2)
TR940	5/16" GM O-Ring w/ 1/2"-20 Nut to Rubber (2)
TR945	5/16" Inverted Flare w/ 1/2"-20 Nut to Rubber (2)
TR950	5/16" Rubber to Rubber Connector (2)
TR955	5/16" Quick Connect to Rubber (2)
TR960	3/8" to 5/16" Rubber to Rubber Connector (2)
TR965	3/8" Quick Connect to Rubber (2)
TR970	3/8" GM 45° Male to Rubber (2)
TR975	3/8" GM 90° Male to Rubber (2)
TR980	3/8" GM Straight Male to Rubber (2)
TR985	3/8" Inverted Flare to Rubber (2)
TR990	3/8" GM O-Ring to Rubber (2)

TOOLS & ACCESSORIES

PART #	DESCRIPTION	COST
CL12	1/2" Hanger Clamps (10)
CP90	Heavy Duty Ratcheting Seal Clamp Pliers (1)
CP360	360° Seal Clamp Pliers (1)
TC35	Tube & Hose Cutter (1)
K6806	9/16" Seal Clamp (10)
TR775	3/8" Trany Connector Clip (5)

company

Thermoid

HBD Thermoid a subsidiary of HBD Industries Inc. is a premier American manufacturer of industrial rubber products with a legacy dating back to 1883. Headquartered in Dublin Ohio the company operates major manufacturing facilities in Bellefontaine (Ohio) Chanute (Kansas) and Oneida (Tennessee).

HEATER HOSE

SIZE	PART#	EACH	10 ASST	20 ASST
1/2" X 50" RED	1835
1/2" X 50' BLK	1725
5/8" X 50' BLK	1726
3/4" X 50' BLK	1727
1" X 50' BLK	1728

FUEL LINE

SIZE	PART#	EACH	10 ASST	20 ASST
3/16" X 25'	24048
1/4" X 25'	24060
5/16" X 25'	24078
3/8" X 25'	24088
7/16" X 25'	24106

PREMIUM FUEL LINE

SIZE	PART#	EACH	10 ASST	20 ASST
3/16" X 25'	25048
1/4" X 25'	25060
1/4" X 250'	25068
5/16" X 25'	25078
3/8" X 25'	25088
3/8" X 250'	25100

VACUUM HOSE

SIZE	PART#	EACH	10 ASST	20 ASST
3/32" X 50'	333850
7/64" X 50'	333950
5/32" X 50'	334050
7/32" X 50'	334150
9/32" X 50'	334250

AIR HOSE

SIZE	PART#	EACH	10 ASST	20 ASST
1/4" X 50' RED	522-50
3/8" X 25' RED	538-25
3/8" X 50' RED	538-50
1/2" X 50' RED	412-50

BELL HOSE

SIZE	PART#	EACH	10 ASST	20 ASST
3/8" X 100	520-100
